Altec Lansing CD308-16T User Manual
Page 4
CD308-SS REV06
TRANSFORMER CHART
WIRING DIAGRAM
CD308
YELLOW
0.5 dB
1.0 dB
8 Ω
ORANGE
RED
BROWN
COMMON
BLACK/WHITE
BLACK LEAD
COMMON
+
-
Premium 4 W
Premium 8 W
Premium 16 W
70.7 V
100 V
Transformer
Transformer
Transformer
Primary Tap
Primary Tap
(T504-71)
(T508-71)
(T516-71)
Color Code
Color Code
Primary
Primary
Primary
4.0 W
8.0 W
16.0 W
Brown
Red
2.0 W
4.0 W
8.0 W
Red
Orange
1.0 W
2.0 W
4.0 W
Orange
Yellow
0.5 W
1.0 W
2.0 W
Yellow
N/A
Primary Common
Black
