Amcor AHD-65E - Manual (Page 3)

7
Specifications
Model Number AHD-65E
Automatic Humidistat Control Yes
Automatic Shut Off Yes
Refrigerant R-22
Power Supply 115V / 60Hz
Humidity Removal Capacity 65 pints / Day
Fan Speed 2-Speed
Weight 43.2 lbs.
Dimensions 14.375"W x 22.25"D x 13.375"H
REMARKS:
The dehumidification may be affected by the height of
the ceiling, quality of insulation, number of windows, etc.
2
Proper Use and Care
• Place the dehumidifier in a location that does not restrict air flow into the rear coil or
out of the front grille.
• The dehumidifier must be operated in an enclosed area to be most effective.
Close all doors, windows and other outside openings to the room.
• A dehumidifier operating in a basement will have little or no effect in drying an adjacent
enclosed storage area (such as a closet) unless there is adequate circulation of air in and
out of the area.
• If the “BUCKET FULL” light comes on when using the unit for the first time,
take the bucket out and put it in again. The light will go off.
• Turn the dehumidifier off and remove the plug from the wall outlet before cleaning.
Use water and a mild detergent to clean the inlet and outlet grilles. Do not use bleach
or abrasives.
The air filter is on the front of the dehumidifier. It should be checked and cleaned at
least every 2 to 3 weeks or when needed.
• To Remove Filter: Unplug the unit, remove the bucket and lift out the filter.
Clean the filter with a vacuum cleaner or wash it with clean water and dry it
with a dry cloth.
Maintenance
