Specifications
INTERCHANGEABLE LENS FOR DIGITAL CAMERA
“LUMIX G VARIO 100 – 300 mm/F4.0 – 5.6/MEGA O.I.S.”
Focal length f=100 mm to 300 mm
(35 mm film camera equivalent: 200 mm to 600 mm)
Aperture type 7 diaphragm blades/circular aperture diaphragm
Aperture range F4.0 (Wide) to F5.6 (Tele)
Minimum aperture value F22
Lens construction 17 elements in 12 groups (1 ED lens)
In focus distance 1.5 m to ¶ (from the focus distance reference line)
Maximum image magnification 0.21k (35 mm film camera equivalent: 0.42k)
Optical image stabilizer Available
Mount “Micro Four Thirds Mount”
Angle of view 12x (Wide) to 4.1x (Tele)
Filter diameter 67 mm
Max. diameter Approx. 73.6 mm
Overall length Approx. 126 mm
(from the tip of the lens to the base side of the lens mount)
Mass Approx. 520 g
