WM-700™ LAvALIER OPERATION
Receiver Set Up
1. Plug the included power supply into the DC input connector on the back of the receiver.
2. Plug the other end of the power supply into an power outlet.
Note: Make sure the squelch on the receiver is turned the minimum.
Lavalier Set Up
1. Insert two AA batteries into the back battery compartment of the lavalier bodypack.
2. Connect the headset to the bodypack via the attached mini XLR cable. Make sure the Gain con-
trol located on the bottom right side of the bodypack is set to a minimum level.
Connecting the Receiver Output
1. You can connect the receiver to a output source using a cable with an 1/4’’ jack or 3-pin XLR
female connection.
2. Connect one end of the cable to the receiver, and the other end into the mic input of a mixer, PA
system, or amplifier. Set the Mic/Line switch accordingly on both the receiver and lavalier.
WM-700™ LAvALIER SYSTEM SET UP
1. Plug the receiver in and press the power button for 2 seconds to turn “On” the receiver.
Note: Make sure the squelch on the receiver is turned the minimum before switching on
the power.
2. Set your desired mode by pressing and holding the UP or DOWN buttons. Every 2 seconds the
receiver will switch to the next mode, release the button when you reach your desired mode.
3. Set the Channel by pressing and holding the SET button for 3 seconds or until it starts to flash.
Press the UP and DOWN buttons to select your desired channel. After you have found your
desired channel or an interference free channel release the button and let the LCD flash 5 times
and your selection will be locked into the channel setting.
4. Press the power button located on the top of the lavalier for 1 second. Press the power button
so that the channel display begins to flash.
Set the lavalier to the same channel as the receiver by pressing the either the channel UP or
DOWN buttons to find the same channel as the receiver. After you have found the same channel
let the LCD flash 5 times and your selection will be locked into the channel setting. Set the
Mic/Line switch located on the back of the lavalier accordingly.
If the signal from the lavalier is being received by the receiver the RF Segment meter will light up
and let you know how strong the signal is.
5. Speak, sing, or play your instrument at a typical level. Adjust the receiver volume control accord-
ingly. The AF Segment meter will light up and let you know how strong the signal is.
6. When finished, turn the lavalier “Off” by pressing the power button for 2 seconds. Then press the
power button on the receiver for 2 seconds to turn it “Off”.
