Panasonic MC-CL935 - Manual (Page 44)

End Cap
Bouchon
Tapa del extremo
Brush Unit
Agitateur
Unidad del cepillo
Belt Path
Chemin de courroie
Ruta de la correa
End Cap
Bouchon
Tapa del extremo
NOTE: In order to keep cleaning
efficiency high and to prevent damage
to your vacuum cleaner, the agitator
must be cleaned every time the belt is
changed.
➢ Check and remove hair, string and
lint build-up frequently in the Power
Nozzle agitator and end cap areas.
➢ Remove any dirt or debris in the
belt path area or in the brush roller
area.
➢ Carefully remove any string or
debris located on the agitator or
end caps.
Agitator Assembly
Assemblage de l’agitateur
Ensamble del agitador
Agitator Cleaning
➢ Remove POWER NOZZLE cover.
➢ Remove the light bulb by pulling
straight out.
➢ To replace the light bulb, carefully
insert fully into slot.
➢ Only use a bulb rated 13V AC- 9
Watts.
➢ Replace POWER NOZZLE cover.
Replacing Headlight Bulb
TO CHECK BRUSHES:
➢ When brushes are worn to the
level of the base support bar,
replace the agitator.
➢ To replace agitator assembly see
BELT CHANGING, p. 40.
Base Support Bars
Barres de support de la base
Barra de soporte de la base
New Brushes
Nouvelles brosses
Cepillos Nuevos
Worn Brushes
Brosses usées
Cepillos desgastado
Brush Servicing
- 44 -
