- 1 -
VII
.
SPECIFICATIONS
MAIN UNIT
Model EY7410
Capacity
Screw driving Machine screw
M.5 - M5
Wood screw ø 3.8 x 38 mm (5/3 " x 1-9/64 " )
Drilling For metal ø 5 mm (13/64 " ) spc t = 1.6 mm
Motor 3.6 V DC
No load speed
LOW: 00 /min (rpm)
HIGH: 600 /min (rpm)
Maximum clutch torque 3.0 N·m (30 kgf-cm, 6 in-lbs)
Overall length 76 mm (10-55/64 " )
Weight (with battery pack) 0.5 kg (1.1 lbs)
BATTERY PACK
Model EY9L10
Storage battery Li-ion Battery
Battery voltage 3.6 V DC (3.6 V x 1 cell)
Capacity 1.5 Ah
BATTERY CHARGER
Model EY0L10
Weight 0.6 kg (1.3 lbs)
Electrical rating See the rating plate on the bottom of the charger.
Charging time
.4 V 3.6 V
1. Ah
EY901
15 min.
EY905
15 min.
1.5 Ah
EY9L10
Usable: 15 min.
Full: 30 min.
NOTE:
• For applicable battery packs to this charger, see the label on the charger or the latest
general catalog.
