10
English
Attachingorremovingthecombattachments
• Make sure that the clipper is turned off.
► 1mmcombattachment
Attach/remove the comb attachment to/from the main body.
• It will make a clicking sound when attached correctly.
► Trimmingheightcombattachment
Attach to/remove from the main body while pressing on the 3 mm
adjustment buttons.
• It will make a clicking sound when attached correctly.
Usingthetrimmingheightcombattachment
• Make sure that the clipper is turned off.
1. Mount the trimming height comb
attachment to the main body.
2. Slide up and down while pressing on
the 3 mm adjustment buttons.
3. Slide the trimming height adjustment
lever to the left or right and adjust the
trimming height indication mark to the
number indicating the desired length.
Trimming
length
(estimate)
3mm
adjustment
scaleandthe
3mm
adjustment
indicator
positions
Thetrimmingheightadjustment
leverandthetrimmingheight
indicatorpositions
2 mm
(5/64˝)
2 mm
(5/64˝)
3 mm
(1/8˝)
4 mm
(5/32˝)
3 mm
(1/8˝)
4 mm
(5/32˝)
5 mm
(3/16˝)
5 mm
(3/16˝)
6 mm
(15/64˝)
7 mm
(9/32˝)
6 mm
(15/64˝)
7 mm
(9/32˝)
8 mm
(5/16˝)
8 mm
(5/16˝)
9 mm
(23/64˝)
10 mm
(13/32˝)
9 mm
(23/64˝)
10 mm
(13/32˝)
• To trim to 1 mm (1/32˝) length, use the 1 mm comb attachment.
• It can also be used without the comb attachment.
(Trimming height: approx. 0.5 mm (1/64˝))
• Actual hair length will be a little longer than the height you set.
