Drive a screw into the wall.
≥ Use the measurements indicated below to identify the screwing positions on the wall.
≥ Leave at least 20 mm (
25
/
32
q) of space above of the main unit to allow enough space for fitting the main unit.
≥ Leave at least 10 mm (
13
/
32
q) of space on both sides of the main unit. Without sufficient space, it is not possible to
mount the main unit successfully.
≥ Be sure to use a level to insure that both mounting holes are level to each other.
Front view (semi-transparent image)
Fit the main unit securely onto the screw(s).
Secure the cord to the wall.
≥ Make sure that the slack of the cord is minimal.
M Screw eye
N Cord
B At least 30 mm (1
3
/
16
q)
C
‰4.0 mm (
5
/
32
q)
D
‰7.5 mm to ‰9.4 mm (
9
/
32
q to
3
/
8
q)
E Wall or pillar
F 7.5 mm to 8.5 mm (
7
/
32
q to
11
/
32
q)
G 320 mm (12
19
/
32
q)
H 215 mm (8
15
/
32
q)
I 215 mm (8
15
/
32
q)
J 15 mm (
19
/
32
q)
K 115 mm (4
17
/
32
q)
L Wall mounting hole
DO
DO NOT
≥ Move the speaker so
that the screw is in this
position.
≥ In this position, the
speaker will likely fall if
moved to the left or right.
