ATTENTION!
To ensure correct parts supply,please let us know the following,
Part No. when you make service parts order:
S-26PU1U6
1.Part No. 2.Description 3.Q'ty 4.Volts-Hz-Ph 5.Product Mode No.
INDOOR UNIT
Description
Model Number
Q'ty
Reference No.
*
1
CV 6233010830 Heat Exch Ass'y
1
8540412458300
*
2
CV 6233196534 Fan Motor Ass'y
SFG6X-41D6P
1
8FA0520219300
*
3
CV 6231191050 Fixed Capacitor
UP44B455J0300D
1
4223956862
*
4
CV 6231916783 Fuse
MT3 5A
2
1FJ4S3A003900
*
5
CV 6233196527 Terminal Base
UKT50-3+15S-2J-SA4117
1
1FA4J3A048900
*
6
CV 6231656726 Capillary Tube
1
8542423717100
*
7
CV 6233196510 Switch Ass'y
FS-0218-102
1
8FA0515209000
*
8
CV 6233196503 Circuit Board Ass'y
CR-26PU1U6-P
1
8549953605983
*
9
CV 6233197296 Thermistor Ass'y
KTEC-35-S6
1
8FA0525963900
*
10
CV 6233196558 Thermistor Ass'y(E1)
PBC-41E-S14
1
8FA0525961900
11
CV 6231592888 Cabinet Ass'y
1
8540110432900
*
12
CV 6233196541 Motor Pump Ass'y
PLD-12230ST-6
1
8FA0526415200
13
CV 6230936508 Washer
3
3902103100
*
14
CV 6380082971 Fan Ass'y
1
8540250121610
15
CV 6380197651 Cushion Rubber
3
8542253417800
16
CV 6380197668 Drain Hose
1
8542429714700
17
CV 6230709300 Strainer Ass'y
1
8540452210400
*
18
CV 6231656757 Capillary Tube
1
8542423717200
*
19
CV 6231656740 Capillary Tube
1
8542423717300
20
CV 6231916837 Mounting Plate, Drain Pan
1
85422333221H2
21
CV 6231608206 Insulation Special
1
8542241124110
22
CV 6231608213 Insulation Special
1
8542241124020
*
23
CV 6231916820 Transformer Ass'y
ATR-IIK224A
1
8540526319000
24
CV 6231916813 Cover Ass'y, Evaporator
1
85402317169H2
25
CV 6231916875 Cabinet Plate
1
85421105298H2
26
CV 6231916868 Mounting Plate
1
85424134664H1
*
27
CV 6231916851 Drain Pan Ass'y
1
85402301515H2
28
CV 6380197712 Mounting Plate, Drain Pan
1
8542233322001
29
CV 6231019132 Cap Rubber
1
8542410910200
30
CV 6231916844 Mounting Plate
1
85422361512H2
31
CV 6380197736 Mounting Parts Ass'y
2
8540111120301
32
CV 6380197743 Mounting Parts Ass'y
2
8540111120401
33
CV 6380148165 Joint Drain
1
8542233417310
34
CV 6231608336 Support Wire
1
8542531911101
35
CV 6233196565 Elec. Wiring Diagram
1
8FA2525103700
36
CV 6380197767 Cover,Elec.Component Box
1
8542530450801
37
CV 6231608138 Elec Component Box Ass'y
1
8540530180300
38
CV 6230383425 Bushing
OCB-875
1
8512537000900
39
CV 6231263856 Washer Special
1
8542135515201
40
CV 6231608145 Nozzle
1
8542251914310
NOTE:
Metal and plastic parts will be supplied basically
with necessary heat insulation pads or packing.
Each key number with an asterisk (*) means the
recommended service parts.
KeyNo.
Part No.
- 26 -
