136
„ Ceiling (T1 type)
Model Name S-36PT1E5 S-45PT1E5 S-50PT1E5 S-60PT1E5 S-71PT1E5 S-100PT1E5 S-125PT1E5 S-140PT1E5
Power Source 220 - 230 - 240 V, single-phase, 50/60 Hz
Cooling capacity
kW 3.6 4.5 5.0 6.0 7.1 10.0 12.5 14.0
BTU / h 12,300 15,400 17,100 20,500 24,200 34,100 42,700 47,800
Heating capacity
kW 4.2 5.2 5.6 7.0 8.0 11.2 14.0 16.0
BTU / h 14,300 17,700 19,100 23,900 27,300 38,200 47,800 54,600
Sound
Pressure
level
High dB(A) 35 38 38 39 39 42 45 46
Medium dB(A) 32 33 33 36 36 38 40 41
Low dB(A) 30 30 30 33 33 35 37 38
Sound
Power level
High dB(A) 53 57 57 58 58 61 63 64
Medium dB(A) 50 51 51 53 53 56 58 59
Low dB(A) 46 46 46 50 50 53 55 56
Unit Dimensions (H×W×D) mm 210Ч910Ч680 210Ч910Ч680 210Ч910Ч680 210Ч1,180Ч680 210Ч1,180Ч680 210Ч1,595Ч680 210Ч1,595Ч680 210Ч1,595Ч680
Net weight kg 21 21 21 25 25 33 33 33
SPECIFICATIONS
