24
RQT9759
Specifications
≥ Specifications are subject to change without notice.
Mass and dimensions are approximate.
≥ Total harmonic distortion is measured by a digital spectrum
analyzer.
*1: When the iPod/iPhone/iPad is not charging and the dock is
closed.
*2: MPEG-1 Layer 3, MPEG-2 Layer 3
∫ GENERAL
Power consumption 37 W
Power consumption in standby mode* 1
Approx. 0.2 W
Power consumption in standby mode
(With the iPod dock open)
Approx. 0.5 W
(With “NET STNBY” set to “ON”)
Approx. 6.5 W
Power supply
AC 220 V to 240 V, 50 Hz
Dimensions (WkHkD)
500 mmk204 mmk84 mm
(Depth without stand: 75 mm)
Mass Approx. 2.6 kg
Operating temperature range
0 oC to r40 oC
Operating humidity range
35 % to 80 % RH (no condensation)
∫ AMPLIFIER SECTION
Output power
RMS Output Power Stereo mode
Front Ch (both ch driven)
20 W per channel (6 ≠), 1 kHz, 10 % THD
Total RMS Stereo mode power
40 W
∫ TUNER SECTION
Preset Memory FM 30 stations
Frequency Modulation (FM)
Frequency range
87.50 MHz to 108.00 MHz (50 kHz step)
Antenna terminals
75 ≠ (unbalanced)
∫ DISC SECTION
Disc played (8 cm or 12 cm)
CD, CD-R/RW (CD-DA, MP3* 2 )
Pick up
Wavelength 790 nm (CD)
[NORSK]
Bølgelengde
790 nm (CD)
Laserstyrke Ingen farlig stråling sendes ut
(med sikkerhets-beskyttelse)
Audio output (Disc)
Number of channels
2 ch (FL, FR)
∫ SPEAKER SYSTEM SECTION
Type
1 way, 1 speaker system (Passive Radiator)
Speaker unit(s)
Full range
6.5 cm Cone typek1 per channel
Passive Radiator
8 cmk2 per channel
Impedance 6 ≠
∫ TERMINAL SECTION
“IPOD_DOCK” connection
DC OUT 5 V 1.0 A MAX
“IPOD_PORT” connection
DC OUT 5 V 2.1 A MAX
USB Standard
USB 2.0 full speed
Media file format support
MP3 (¢.mp3)
USB device file system
FAT12, FAT16, FAT32
Phone jack
Terminal Stereo, ‰3.5 mm jack
∫ Wi-Fi/AirPlay SECTION
Wi-Fi
WLAN Standards IEEE802.11b/g
Frequency range 2.4 GHz band
Security WEP, WPA TM , WPA2 TM
WPS version
Version 2.0 (WEP not support)
∫ BLUETOOTH SECTION
Bluetooth ® system specification V 3.0
Wireless equipment classification
Class 2
Supported profiles
A2DP, AVRCP, GAVDP
Frequency band
2402 MHz to 2480 MHz
(Adaptive Frequency Hopping)
Driving distance 10 m Line of sight
