[Note]
1 Specifications are subject to change without notice.
Mass and dimensions are approximate.
2 Total harmonic distortion is measured by a digital spectrum analyzer.
Specifications
AMPLIFIER SECTION
RMS Output Power: Dolby Digital Mode
Front Ch
Surround Ch
Center Ch
Subwoofer Ch 55 W per channel (5 ≠), 1 kHz, 10 % THD
55 W per channel (5 ≠), 1 kHz, 10 % THD
55 W per channel (5 ≠), 1 kHz, 10 % THD
55 W per channel (5 ≠), 100 Hz, 10 % THD
Total RMS Dolby Digital mode power 330 W
FM TUNER, TERMINALS SECTION
Preset Memory FM 30 stations
Frequency Modulation (FM)
Frequency range 87.50 MHz to 108.00 MHz (50-kHz step)
Antenna terminals 75 ≠ (unbalanced)
Digital audio input
Optical digital input
Sampling frequency Optical terminal
32 kHz, 44.1 kHz, 48 kHz
USB Port
USB standard
Media file format support USB 2.0 full speed
MP3 (¢.mp3)
WMA (¢.wma)
JPEG (¢.jpg, ¢.jpeg)
DivX (¢.divx, ¢.avi)
MPEG4 (¢.asf)
USB device file system
USB Port power
Bit rate FAT12, FAT16, FAT32
Max. 500 mA
Up to 4 Mbps (DivX)
Music Port (Front)
Sensitivity 100 mV, 6.8 k≠
Terminal Stereo, 3.5 mm jack
DISC SECTION
Discs played (8 cm or 12 cm)
(1) DVD (DVD-Video, DivX §5, 6 )
(2) DVD-R (DVD-Video, DVD-VR, MP3 §2, 5 , JPEG §4, 5 , MPEG4 §5, 7 ,
DivX §5, 6 )
(3) DVD-R DL (DVD-Video, DVD-VR, DivX §5, 6 )
(4) DVD-RW (DVD-Video, DVD-VR, MP3 §2, 5 , JPEG §4, 5 , MPEG4 §5, 7 ,
DivX §5, 6 )
(5) iR/iRW (Video)
(6) iR DL (Video)
(7) CD, CD-R/RW (CD-DA, Video CD, SVCD §1 , MP3 §2, 5 , WMA §3, 5 ,
JPEG §4, 5 , MPEG4 §5, 7 , DivX §5, 6 )
§1 Conforming to IEC62107
§2 MPEG-1 Layer 3, MPEG-2 Layer 3
§3 Windows Media Audio Ver.9.0 L3
Not compatible with Multiple Bit Rate (MBR)
§4 Exif Ver 2.1 JPEG Baseline files
Picture resolution: between 160k120 and 6144k4096 pixels (Sub
sampling is 4:0:0, 4:2:0, 4:2:2 or 4:4:4). Extremely long and narrow
pictures may not be displayed.
§5 The total combined maximum number of recognizable audio,
picture and video contents and groups: 4000 audio, picture and
video contents and 255 groups. (Excluding Root folder)
§6 Plays DivX ® video.
§7 MPEG4 data recorded with Panasonic SD multi cameras or DVD
video recorders
Conforming to SD VIDEO specifications (ASF standard)/MPEG4
(Simple Profile) video system/G.726 audio system
Pick up
Wavelength (DVD/CD) 655/790 nm
Laser power (DVD/CD) CLASS 1M/CLASS 1M
Audio output (Disc)
Number of channels 5.1 ch (FL, FR, C, SL, SR, SW)
VIDEO SECTION
Video system PAL625/50, PAL525/60, NTSC
Composite video output
Output level
Terminal 1 Vp-p (75 ≠)
SCART jack (1 system)
S-video output
Y output level
C output level
Terminal
1 Vp-p (75 ≠)
PAL; 0.3 Vp-p (75 ≠)
NTSC; 0.286 Vp-p (75 ≠)
SCART jack (1 system)
RGB video output
R output level
G output level
B output level
Terminal 0.7 Vp-p (75 ≠)
0.7 Vp-p (75 ≠)
0.7 Vp-p (75 ≠)
SCART jack (1 system)
HDMI AV output
Terminal 19-pin type A connector
HDAVI Control This unit supports “HDAVI Control 4” function.
SPEAKER SECTION
[Front\speakers\SB-HF85]
Type
Speaker unit(s)
1 way, 1 speaker system (Bass reflex)
Impedance 5 ≠
Full range 6.5 cm Cone type
Output sound pressure
Frequency range
Dimensions (WtHtD)
Mass
79 dB/W (1 m)
80 Hz to 25 kHz (j16 dB)
90 Hz to 22 kHz (j10 dB)
100 mmk530 mmk78 mm
0.88 kg
Full assembly with stand base
Dimensions (WtHtD) max
Dimensions (WtHtD) min
Mass
255 mmk1020 mmk255 mm
255 mmk550 mmk255 mm
2.3 kg
[Surround\speakers\SB-HS85]
Type
Speaker unit(s)
1 way, 1 speaker system (Bass reflex)
Impedance 5 ≠
Full range 6.5 cm Cone type
Output sound pressure
Frequency range
Dimensions (WtHtD)
Mass
78 dB/W (1 m)
85 Hz to 25 kHz (j16 dB)
150 Hz to 22 kHz (j10 dB)
80 mmk118.5 mmk68 mm
0.34 kg
[Center\speaker\SB-HC85]
Type
Speaker unit(s)
1 way, 1 speaker system (Bass reflex)
Impedance 5 ≠
Full range 6.5 cm Cone type
Output sound pressure
Frequency range
Dimensions (WtHtD)
Mass
79 dB/W (1 m)
80 Hz to 25 kHz (j16 dB)
130 Hz to 22 kHz (j10 dB)
145 mmk85 mmk71.5 mm
0.44 kg
[Subwoofer\SB-HW70]
Type
Speaker unit(s)
1 way, 1 speaker system (Bass reflex)
Impedance 5 ≠
Woofer 12 cm Cone type
Output sound pressure
Frequency range
Dimensions (WtHtD)
Mass
79 dB/W (1 m)
35 Hz to 350 Hz (j16 dB)
40 Hz to 200 Hz (j10 dB)
130 mmk278 mmk230 mm
2.2 kg
GENERAL
Power supply
Power consumption
Dimensions (WtHtD)
Mass
Operating temperature range
Operating humidity range
AC 220 V to 240 V, 50 Hz
Main unit 47 W
360 mmk58 mmk239 mm
Main unit 2.0 kg
0 oC to r40 oC
35 % to 80 % RH (no condensation)
Power consumption in standby mode approx. 0.48 W
