Basic Connection

External equipment and cables shown are not supplied with this TV.
Please ensure that the unit is disconnected from the mains socket before attaching or disconnecting any leads.

Terminals

1 HDMI 2 (p. 9)

2 DIGITAL AUDIO

3 AV 1 (SCART) (p. 9)

4 AV 2 (COMPONENT / VIDEO)

5 HDMI 1 (ARC) (p. 9)

6 Terrestrial terminal (see below)

7 CI slot

8 Headphone jack

9 USB port

Connections

Mains lead and aerial

Mains lead

RF cable

Insert the mains plug (supplied) firmly into

place.

●

When disconnecting the mains lead,

be absolutely sure to disconnect the mains plug

at the socket outlet first.

Terrestrial aerial

Cable

Antenna, Cable

Mains Lead

AC 220-240 V

50/60 Hz

If the antenna is placed in the wrong location, interference might happen.
