[1] Door Release Pad

Press to open the door. When you open the oven door during cooking, the cooking is stopped

temporarily without clearing earlier made settings. Cooking resumes as soon as the door is

closed and Start is pressed.

[2] Oven Window

[3] Door Safety Lock System

[4] Oven Air Vent

[5] Control Panel

[6] Glass Tray

[7] Roller Ring

[5]

[2]

[3]

[4]

[6]

Outline Diagram

En-4

[1]

[7]
