Panasonic SCNE1EG - Manual (Page 10)

10
VQT4U48
Specifications
* Prospective communication distance
Measurement environment:
Temperature 25 oC / Height 1 m
Measure in “MODE 1”
≥ Specifications are subject to change without notice.
Mass and dimensions are approximate.
≥ Total harmonic distortion is measured by a digital spectrum
analyzer.
∫ GENERAL
Power consumption 11 W
Power consumption in standby mode
Approx. 0.2 W
Power supply
AC 220 V to 240 V, 50 Hz
Dimensions (WkHkD)
570 mmk206 mmk100 mm
Mass Approx. 2.7 kg
Operating temperature range 0 oC to r40 oC
Operating humidity range
35 % to 80 % RH (no condensation)
∫ AMPLIFIER SECTION
RMS Output Power Stereo mode
Front Ch (both ch driven)
20 W per channel (6 ≠), 1 kHz, 10 % THD
Total RMS Stereo mode power 40 W
∫ SPEAKER SECTION
Type
2 way, 2 speaker system (Bass reflex)
Speaker unit(s)
1. Woofer 8 cmk1 per channel
2. Tweeter 2.5 cmk1 per channel
Impedance 6 ≠
Output sound pressure 83.5 dB/W (1 m)
Frequency range 52 Hz to 25 kHz (s16 dB),
75 Hz to 22 kHz (s10 dB)
∫ BLUETOOTH SECTION
Version Bluetooth ® Ver.2.1 +EDR
Output Class 2 (2.5 mW)
Communication distance About 10 m*
Communication method 2.4 GHz band FH-SS
Correspondence profile A2DP
∫ TERMINALS SECTION
AUX Terminal Stereo, ‰3.5 mm jack
