User’s Manual for Advantech SOM-A2558 series module V1.00
11
1.2 System Specifications
The following table is SOM-A2558 series functional specifications.
SOM-A2558 standard product specification table
Model
Func.
SOM-A2558-440B0
Reconfiguration
Option
CPU PXA255- 400MHz 200/300/400 MHz
I/O Enhance Chip Advantech EVA-C210 -
Graphic Chip PXA255 built-in -
System
Memory(SDRAM)
64MB SDRAM 16/32/64/128 MB
Boot loader Flash 1MB NOR Flash -
On-board Flash
(Image &
Storage )
0MB 0/16/32/64MB
OS Image
Storage
Thru CFC -
AMI Bus(X1 bus)
100-pin B2B conn w/
buffer drive
Yes
Feature
Extension Bus
(X2 Bus) 100-pin B2B conn (the
conn. Include PCI,ZV &
SD/MMC I/F)
Yes
Watch Dog PXA255 Built-in -
RTC EVA-C210 Built-in -
System Backup
battery
For RTC/SDRAM -
Serial Port
3x Full RS-232 (TTL);
1x 2-wires RS-232
(TTL);
1x 3-wires for RS-232
or RS-485
-
Ethernet 1x 10/100 Base-T -
PCMCIA/
Compact Flash 2 Slots PCMCIA/CF or
1xPCMCIA & 1xCF
-
USB Host 2x USB 1.1 Host -
USB Client 1x USB 1.1 Client -
SD/MMC
1xCh( support 1 bit
memory mode)
PS/2 2x Ch for K/B & MS -
LCD( TTL level)
Up to VGA LCD-16-bit
TFT/STN/DSTN
-
T/S 4-wire resistive Yes
Audio Codec
AC’97 codec on board.
Support Mic-in,
Line-in, Line-out
speaker-out
Yes
Buzzer control Yes -
SM Bus Yes -
