Specifications
INTERCHANGEABLE LENS FOR DIGITAL CAMERA
“LUMIX G VARIO 14–45 mm/F3.5–5.6 ASPH./MEGA O.I.S.”
Focal length f=14 mm to 45 mm
(35 mm film camera equivalent: 28 mm to 90 mm)
Aperture type 7 leaf shutters/iris diaphragm/circular diaphragm
Aperture range F3.5 (Wide) to F5.6 (Tele)
Minimum aperture value F22
Lens construction 12 elements in 9 groups (1 aspherical lenses)
In focus distance 0.3 m to ¶ (from the focus distance reference line)
Maximum image magnification 0.17k (35 mm film camera equivalent: 0.34k)
Optical image stabilizer Available
Mount “Micro Four Thirds Mount”
Angle of view 75x (Wide) to 27x (Tele)
Filter diameter 52 mm
Max. diameter 60 mm
Overall length Approx. 60 mm
(from the tip of the lens to the base side of the lens mount)
Mass Approx. 195 g
