ArtDio IPS-3101h - Manual (Page 7)

User’s Manaul
7
2.3 Hardware Specification
The table below describes the difference among these models.
Model IPS-3101h
LAN interface 1xRJ45 10Base-T
WAN interface 1xRJ45 10Base-T
FXS telephone port 1xFXS
PSTN port 1x life line port
Button 1
LED
Green and red color
Universal Switching
Power Adaptor
Input: 100-240VAC 50-60 Hz
Output: +5VDC, 1200mA,
UL certified
Dimension
70mm (W)
130mm (D)
27mm (H)
Weight 0.6lbs (0.3kg)
Temperature
40 - 130
o
F
5 – 45
o
C
Humidity
10% - 90%
(non-condensing)
Compliance
