7
Connections
AV & COMPONENT Connection
RGB signal (R, G, B, HD, VD)
PC IN
AUDIO
SLOT1
S VIDEO IN
VIDEO IN VD HD P R /C R /R P B /C B /B Y/G
COMPONENT/RGB IN AV
SLOT2 SLOT3
R AUDIO L
IN
R AUDIO L VIDEO OUT
VIDEO
OUT
VIDEO IN
S VIDEO
OUT AUDIO
OUT
R L
AUDIO
OUT
Y, P B , P R ,
OUT
R R
P B
Y
L
R
COMPONENT VIDEO OUT
DVD
VIDEO IN VD HD P R /C R /R P B /C B /B Y/G
COMPONENT/RGB IN AV
R AUDIO L VIDEO OUT
Computer RGB Camcorder
Notes:
(1) The S Video input will override the composite video signal when S Video lead is connected.
(2) Change the “Component/RGB-in” setting in the “Setup” menu to “Component”.
(3) Additional equipment and cables shown are not supplied with this set.
Notes:
(1) Change the “Component/RGB-in” setting in the “Setup” menu to “RGB”.
(2) Additional equipment and cables shown are not supplied with this set.
VCR/S-VIDEO VCR
CAMCORDER
MONITOR
RCA-BNC
adapter
plug
Example of input signal source
Example of input signal source
Digital TV Set-Top-Box
English
