6
CAUTION
• Switch off the power supply before cleaning.
• Do not touch the aluminium fin, sharp parts may cause injury.
1 INDOOR UNIT
• Wipe the unit gently with a soft, dry cloth.
2 FRONT PANEL
Remove Front Panel
• Raise and pull to remove the front panel.
• Wash gently and dry.
Close Front Panel
• Press down both ends of the front panel to close it
securely.
3 RECEIVER
4 ALUMINIUM FIN
5 HORIZONTAL AIRFLOW DIRECTION LOUVER
• Do not adjust by hand.
6 VERTICAL AIRFLOW DIRECTION LOUVER
• Do not adjust by hand.
7 AUTO OFF/ON BUTTON
• Use when remote control is misplaced or malfunction.
Action Mode
Press once. Auto
Press and hold until 1 beep is heard,
then release.
Cooling
Press and hold until 1 beep is heard,
then release.
Press again until 2 beeps, then
release.
Heating
Press the button to turn off.
8 SUPER ALLERU-BUSTER FILTER
Vacuum the super
alleru-buster filter.
• Vacuum the filter whenever necessary.
• Replace the filter every 10 years or replace any
damaged filter.
Part no.: CZ-SA16P
9 AIR FILTERS
• Air filters cleaning is needed every two weeks.
• Wash/rinse the filters gently with water to avoid damage
to the filter surface.
• Dry the filters thoroughly under the shade, away from
fire or direct sunlight.
• Replace any damage filter.
2
5
6
7
1
4
3
9
8
INDOOR UNIT
WASHING INSTRUCTIONS WASHING INSTRUCTIONS HINT HINT
• Do not use benzene, thinner or scouring powder.
• Use only soap ( pH7) or neutral household detergent.
• Do not use water hotter than 40°C.
• To ensure optimal performance of the unit, cleaning
maintenance have to be carried out at regular intervals.
Dirty unit may caused malfunction and you may retrieve
error code “H99”. Please consult authorized dealer.
