Aussie MECO 7110 - Manual (Page 4)

(38) Flame Diffuser
(39) Cooking Grid
(37) Fabric Panel
(43) LP Cylinder
Heat Shield
(41) Main Burner
(42) Main Burner
Electrode
(44) Control Panel
w/Manifold and
Regulator
(40) Warming Rack
ITEM DESCRIPTION PART # QTY.
1 Owner's Manual 03.6602.00 1
2 Bottom Shelf 03.6603.00 1
3 Clip, Cylinder Retainer 03.6205.01 1
4 Left Front Wheel Leg 03.6604.00 1
5 Left Rear Wheel Leg 03.6605.00 1
6 Right Front Fixed Leg 03.6606.00 1
7 Right Rear Fixed Leg 03.6607.00 1
8 Bolt, M5x40 03.6608.00 8
9 Axle 03.6609.00 2
10 Wheel 03.6610.00 2
11 Axle Spring Pin 03.6235.00 2
12 Wheel Cover 03.6611.00 2
13 Hood, Black 03.6612.00 1
14 Hood/Bowl Assembly Black (with Short Handle) 03.6613.00 1
15 Bolt, M6 x 45 03.6614.00 4
16 Locknut, M6 03.4098.00 4
17 Drip Cup 03.6238.00 1
18 Drip Cup Holder 03.6220.00 1
PARTS LIST
4
(36) Front Metal Panel
(35) Hood Handle
(45) Control Knob
(34) Handle Spacer
(Fitted)
(33) Handle Spacer
(Tapered)
