CQ-RX400N/CQ-RX300N/CQ-RX200N 6 CQ-RX400N/CQ-RX300N/CQ-RX200N 7
General (continued)
Source Selection (continued)
(SOURCE)
The source changes as follows every time [SRC] is
pressed.
When an Expansion Module is
Connected to System-up Connector
[CQ-RX200N]
When an Optional Device is
Connected to System-up Connector
Radio
CD or MP3/WMA Player
AUX1
Sources connected to the
Expansion Module (CY-EM100N,
option)
AUX2
Sound source connecting to the AUX input terminal
of Expansion Module
Port 1 (ex. iPod1)
Port 2 (ex. iPod2)
Port 3 (ex. CD changer)
Port 4 (ex. Bluetooth Audio)
Notes:
• Sources change in the order of the port number of
each connected source.
• Unconnected ports are skipped.
Radio
CD or MP3/WMA Player
AUX
Source connected to the System-up Connector
(ex. CD changer)
Shift to connected
device
USB
\CQ-RX400N] \CQ-RX300N]
Caution for USB Device
• Do not connect a USB device directly to this unit.
If the USB device is connected directly to this unit
and an accident occurs, or if the brakes are applied
suddenly, the driver or passenger may bump into the
USB device and may get injured.
• Position the USB device and USB extension cable/
optional adaptor so that they do not obstruct your
driving.
• Do not connect any USB device other than USB
memory or a USB audio player. Do not connect
multiple USB devices to the USB connector. Drawing
power for multiple USB devices from the connector
could cause overheating and smoking.
• This unit plays back MP3/WMA/AAC fi les stored on a
USB memory.
• Back-up any important data beforehand. We cannot
accept responsibility for any lost data.
• Refer to the section on “Compatible USB devices” ( 
Below).
• Refer to the section on “Notes on MP3/WMA/AAC”. ( 
Operating Instructions)
• The fi le for the play time to exceed 1 000 minutes will
not play correctly to the end of the track.
• Connect your USB device to your car audio using a
standard USB extension cable. It is recommended to
use a 2 m or shorter USB 2.0 cable.
• USB Mass Storage Class
This refers to a type of USB device, that when
connected to the PC can be used as a storage device
without the need for specialized drivers or software.
For details as to whether your USB memory/USB Audio
is compatible with USB Mass Storage Class, please
contact the USB memory/USB Audio manufacturer.
• USB Standard Compatibility 1.1/2.0 Full Speed
• File system is FAT12/16/32
• Maximum current less than 500 mA
• Capacity less than 4 GB (1 partition)
Caution for iPod
• Position the iPod and the USB extension cable for
iPod so that they do not obstruct your driving.
Controllable iPod/software version
• 5th generation iPod/ver. 1.2.1 (Video playback is not
supported.)
• 1st generation iPod nano/ver. 1.3.1
• 2nd generation iPod nano/ver. 1.1.3
For the models to be supported, visit the Web Site at
http://panasonic.net (refer to the description regarding
Car Audio/AV).
Notes for USB Device
Notes for iPod
[CQ-RX400N\
• Back-up any important data beforehand. We cannot
accept responsibility for any lost data.
• When an iPod is connected to this unit, operation from
the iPod itself will not be available.
• The iPod will be recharged while connected to this unit.
• Do not leave your iPod for long periods of time in an
area of your vehicle that can become hot.
• Also read the instruction manual provided with your
iPod.
• Make sure to disconnect your iPod after turning off the
car engine (turning the ACC to OFF). The iPod may not
shut down while still connected, which may result in
battery depletion.
• If your iPod is not working correctly, disconnect it from
this unit, reset it and then reconnect it to this unit.
• Do not connect iPod accessories such as the remote
controller or headphones while the iPod is connected to
this unit. Doing so may cause the iPod to not operate
correctly.
Compatible USB devices
Notes:
• The use of USB devices that data fi les other than MP3/
WMA/AAC format stored is not recommended.
• Playback or display may not be possible depending
on the type of USB device or the condition of the
recording.
• Even if PC playback is possible, it may not be
possible on this product, because some USB devices
are not compliant with the USB standard.
• Even with a USB device in the Mass Storage Class,
playback may not be possible in some cases.
