Technical specifications
Panel dimension Diagonal 559 mm (22 inch) LCD monitor
Max. resolution 1,680 x 1,050 / WXGA+
Max. pixel Up to 16.2 M true color
Pixel span Horizontal 0.282mm x Vertical 0.282mm
Brightness 300 cd/m 2
Contrast 700 : 1
LC response time 5 ms
Vis
° °
ual angle Horizontal 170 / Vertical 160
LCD panel
(backlight
source)
Effective display Horizontal 473.8 mm x Vertical 296.1 mm
Signal mode
Simulated video frequency: 0.7 Vpp, 75
Ω
(separate SYNC and composite SYNC)
SYNC
Horizontal 30 kHz – 82 kHz x Vertical 56 Hz – 76
frequency
Hz
Input signal
Max. pixel clock 135MHz
Input terminal I-D (Optional) Image D-Sub 15 PIN (VESA) / DV
Power trans rm – 60 Hz fo er AC100 – 240 Volts, 50
O ration mode 48W pe
Power saving sleep
mode
2W @230VAC 50Hz
Power
consumption
Power saving off mode 1W @230VAC 50Hz
Tem °C – 35°C (operation) / -20°C – 55°C (storage) perature 5
Environmental
conditions
Humidity 20% – 80% (operation) / 20% – 85% (storage)
Actual dimensions (W x D x H) 513.5 x 198.2 x 405.2 mm
Net weight 4.9 kg
Safety standard
CE/EMC;C-Tick; BSMI; ISO
13406-2;EPA;PCT;NOM;WEEE;PSB;HG
TCO03;UL/CUL;TÜV-GS;CE/LVD;TÜV-ERGO;CB;CCC;FCC-B;V
CCI-B;
Lamp disposal
ns and must be recycled or disposed of
according to local, state or federal laws. For more information, contact the
Electronic Industries Alliance at www.eiae.org
Lamp(s) i ide this product contain mercury
. For lamp-specific disposal
information, check www.lamprecycle.org .
9
