En-4
Outline Diagram
[1] Door Release Button
Press to open the door. When you open the oven door during cooking, the cooking is stopped temporarily without clearing
earlier made settings. The cooking is resumed as soon as the door is closed and Start Pad pressed.
The oven lamp lights as soon as the oven door is opened.
[2] Oven Window
[3] Door Safety Lock System
[4] Oven Air Vent
[5] Control Panel
[6] Glass Tray
[7] Roller Ring
[8] External Oven Air Vents
[9] Metal Tray
[10] High Wire Rack
[11] Low Wire Rack
[12] Panacrunch Pan
[13] Panacrunch Pan Handle
[1]
[2]
[3]
[4]
[5]
[7]
[8]
[10]
[6]
[11]
[9]
[12]
[13]
