Specifications
Function ACS-1208AL ACS-1216AL
Computer
Connections Direct 8 16
Max 256 (via Daisy Chain) 512 (via Daisy Chain)
Port Selection OSD (On Screen Display);
Hotkeys
LEDs On Line 8 (Orange) 16 (Orange)
Selected 8 (Green) 16 (Green)
Power 1 (Blue)
Station ID 2 x 7 Segments
Connectors CPU Ports 8 x SPDB-15 F 16 x SPDB-15 F
Daisy Chain 1 x DB-25 M
FW Upgr. 1 x RJ-11
Switches 1 x Slide (FW Upgrade Recovery)
Scan Interval (OSD Select) User Specified: 1 - 255 secs.
Emulation Keyboard PS/2
Mouse PS/2
Video 1024 x 768; DDC2
Power Consumption 120V 60Hz 24W / 230V 50Hz 24W
Operating Temperature 0 - 50
o
C
Storage Temperature -20 - 60
o
C
Humidity 0 - 80% RH
Housing Metal
Weight 13kg 13.5kg
Dimensions (L x W x H) 48.3 x 60 x 4.5 cm (19" / 1U)
2003-01-27
Technical Information
A-3
