OPERATION
Names of Parts
INDOOR UNIT
Wireless Remote Controller (Optional parts)
Refer to the Operating Instructions attached to the
optional Wireless Remote Controller.
OPEN
CLOS
E
CLOSE
OPEN
Intake grille
Control Panel
Airflow direction
louver
Air is discharged
evenly
Receiver
Emergency button
Front panel
Air Filters
Receiver
Emergency button
• Do not adjust
by hand.
• Manually
adjustable.
Vertical airflow
direction louver
Horizontal airflow
direction louver
Y2 type (4-WAY CASSETTE 60×60)
K2 type (WALL MOUNTED)
NOTE
(Wireless type: available
for all indoor units)
