Page 2
2
VQT4V29
Quick Start Guide
STEP 1 : Connecting to a TV
HDMI IN
HDMI cable
[BDT330] Use HDMI AV OUT MAIN terminal.
[BDT233] [BDT230]
[BDT131] [BDT130]
AC mains lead
(supplied)
To a household mains
socket
STEP 2 : Connecting to the network
∫ Wireless LAN connection
[BDT131] [BDT130] For wireless capability, connect the Wireless LAN Adaptor DY-WL5 (optional). Only
DY-WL5 can be used. Read the operating instructions for DY-WL5 thoroughly when using it.
SD CARD
Wireless router, etc.
Internet
[BDT131] [BDT130]
[BDT233] [BDT230]
[BDT330]
∫ LAN cable connection
[BDT330]
[BDT233] [BDT230]
Internet
LAN Cable
[BDT131] [BDT130]
Broadband router, etc.
Use category 5 or above straight LAN cables (STP) when connecting to peripheral devices.
(2)
