Page 12
E-12
VIDEO
IRIS
DC
SET
CAMERA
SETUP
EXT
NOT USED
TERM-OFF
ON
LL
INT/GL
MENU
AWC
ALC
LEVEL
Av Pk
L H
Execute connection/installation according to the procedures described below.
Turn OFF the power supply to all equipment to be used before making carefully.
1.
Mounting the lens
(
੬ Page 14)
4.
Setting the switches
(
੬ Page 17)
6.
Back focus adjustment
(
੬ Page 21)
5.
Lens adjustment
(
੬ Page 20)
7.
Auto white balance
control adjustment
(
੬ Page 22)
3.
Mounting the camera
(
੬ Page 18)
Procedures
CONNECTION/INSTALLATION
