128-7197
16 of 24
16
Note: Resistive Circuits, As Well As 4 Wire Polarity Reversal and 5 Wire Alternating 12 Volt
Door Lock Control Circuits
These applications require the use of additional components which may include relays, fixed resistors, or
for convenience, the AS 9159 Door Lock Interface. Refer to the AUDIOVOX Door Lock Wiring Supple-
ment and or the Audiovox fax back service for information on your particular vehicle for properly connect-
ing to these types of circuits.
ALARM SELECTABLE FEATURES
NOTE: The Alarm Selectable Features and Remote Start Selectable Features programming steps following are
based on transmitter button 1 being programmed for channel 1 and transmitter button 2 being programmed for
channel 2.
RF Programmable Features:
Feature Selection 1 Chirp 2 Chirps 3 Chirps Default
1st Door L/UL 1 Sec. 3.5 Sec. 1 Sec L, Dbl. U/L 1 Sec.
2nd Accy Lock Auto Lock On Auto Lock Off Auto Lock Off
3rd Accy. UL Auto UL Dr Auto UL All Auto Off Auto UL Off
4th Passive Locks Passive Active Active
5th Passive/Active Arm Passive Arm Active Arm Active Arm
6th Siren/Horn Siren/Horn Siren Only Horn Only Siren/Horn
7th Horn Chirp 10mS 16mS 30mS 16mS
8th Override Method Custom Code Valet Valet
9th Two Step Unlock On Off Off
10th Chirp Delete From Tx On Off Off
