1
Application
The Robertshaw 8625 is a multi-stage thermostat designed to control
24 VAC heat pump systems.
Features
• Large back lit display.
• Four preprogrammed E NERGY S TAR ® setpoints for each day of the week.
• Adjustable 1 st stage temperature differential: 1.0°F to 3.0°F (0.5°C to
1.5°C).
• Adjustable 2 nd stage temperature differential: 1.0°F to 6.0°F (0.5°C to
3.0°C).
• Adjustable 2 nd stage delay (10-40 minutes).
• Energy Efficient Recovery (EER™).
• Residual cooling for added air conditioning efficiency.
• Zone compatible as master thermostat.
• Fahrenheit/Celsius display option.
• Programmable from 45°F (4°C) to 90°F (32°C).
• Accuracy within ± 1 degree.
• Separate heating and cooling programs.
110-1101
5 - 2 Day Programmable
2 Heat / 2 Cool
User’s Manual
Quick Start
Installation and
Programming
W
A R R A N T Y
2 TW
O YEAR
DIGITAL
PROGRAMMABLE
THERMOSTAT
862
5
ELECTRIC
E
GAS
G
OIL
O
®
NeW
HEAT PUMP
H
As an E NERGY S TAR ® partner, Climate Controls Americas has determined
that this thermostat product meets the E NERGY S TAR ® guidelines for
energy efficiency.
110-1101 7/22/04 8:16 AM Page 1
