7
FWD-42PX2
Code Table(1-a)
[a]Function
[b]Range/Switch Code
Command
Control
Enquiry
Standby
Power On
0x35
PAP Input Detect
*
2
0x0A INPUT2 RGB
No
Yes
Disable
Enable
(Left/Main)
0x0B INPUT2 COMPONENT
0x0C OPTION1 VIDEO
0x0D OPTION1 S VIDEO
0x0E OPTION1 RGB
0x0F
OPTION1 COMPONENT
0x10
OPTION2 VIDEO
0x11
OPTION2 S VIDEO
0x12
OPTION2 RGB
0x13
OPTION2 COMPONENT
0x20
INPUT1 DVI
0x36
PAP Input Detect*2
0x0A INPUT2 RGB
No
Yes
Disable
Enable
(Right/Sub)
0x0B INPUT2 COMPONENT
0x0C OPTION1 VIDEO
0x0D OPTION1 S VIDEO
0x0E OPTION1 RGB
0x0F
OPTION1 COMPONENT
0x10
OPTION2 VIDEO
0x11
OPTION2 S VIDEO
0x12
OPTION2 RGB
0x13
OPTION2 COMPONENT
0x20
INPUT1 DVI
*
1: Transmit the next command 10 seconds after Power On and Power Off commands are transmitted. If not, correct data may not be able to be acquired.
*
2: The command of Option 2 slot is assigned to Option 1 slot because the BKM-FW32 is installed in Option 2 slot.
*
3: The Picture Position arrangement is as shown below.
IP Address
Syntax
Header
Category
Function
Data1
Data2
Data3
Data4
Data5
Check Sum
Control
0x8C
0x00
0x42
0x05
Address
Address 1
Address 2
Address 3
0xXX
00x00-0xFF
0x00-0xFF
0x00-0xFF
0x00-0xFF
Answer
Header
Answer
Check Sum
Control
0x70
0x00
0x70
Completed
0x70
0x03
0x73
Command Canceled
IP Address ex)
192.128.14.1
→
192 (0xC0)
Address 0
128 (0x80)
Address 1
14
(0x0E)
Address 2
1
(0x01)
Address 3
*
IP Address command can be carried out even in the standby state.
1
2
4
3
