20
VPL-VW100
RemarksItem NumberDataItemUpper byteLower byteDataUpper byteLower byteStatus Error01h01hNo Error00h00hGet onlyLamp Error00h01hFan Error00h02hCover Error00h04hTemp Error00h08hD5V Error00h10hPower Error00h20hTemp Warning Error00h40hNVM Data Error00h80hStatus Power01h02hStanby00h00hStart Up00h01hStart Up Lamp00h02hPower On00h03hCooling100h04hCooling200h05hSaving Cooling100h06hSaving Cooling200h07hSaving Stanby00h08hControl Mode01h05hUser Mode00h00hService Mode00h01hLamp Timer01h13hLamp Use Time0000h-FFFFh *1ROM Version01h1DhMAIN ROM Version*2SC ROM Version01h1EhSC ROM Version*2NVM Data VERSION01h27h NVM data VERSION*3W/B All Save03h04h_00h00hSet onlyW/B Low Save05hW/B High Save06hW/B Middle Save07hW/B Custom1 Save08hW/B Custom2 Save09hW/B Custom3 Save0AhSircs(15 bit category)17hRefer to Table4_00h00hSet only *4Sircs(20 bit category)19hRefer to Table5_00h00h*1 Example) In case the lamp timer indicates 1000H, return values are [03h] upper byte and [E8h] lower byte.
*2 Example) In case the software version is 1.03, return values are [01h] upper byte and [03h] lower byte.
*3 Example) In case the NVM data version is 3, return values are [00] upper byte and [03] lower byte.
*4 It is corresponded to single command only. Pages: 1 … 22 23 24 25 26 … 28 wrong Brand wrong Model non readable See also other documents in the category Sony Home Theater Systems: HT-SL40 (44 pages) HT-SF800M (2 pages) DHC-FL7D (76 pages) DAV-S880 (84 pages) DHC-FL5D (224 pages) DHC-FL5D (76 pages) HT-SL40 (216 pages) HT-SL40 (2 pages) DAV-S550 (84 pages) DAV-LF1 (116 pages) DAV-LF1 (488 pages) DAV-LF1 (2 pages) DAV-LF1 (1 page) DAV-FC8 (92 pages) DAV-HDZ273 (92 pages) DAV-FR8 (1 page) DAV-FR8 (2 pages) DAV-FR8 (1 page) HCD-FR8 (108 pages) IZ1000W (88 pages) IPELATM PCS-HG90 (2 pages) BLU-RAY DISC BDV-T37 (80 pages) HT-DDW990 (80 pages) HT-DDW990 (2 pages) 4-130-029-13(1) (64 pages) HT-SS100 (2 pages) HCD-HDX265 (1 page) HDX267W (104 pages) RHT-G2000 (12 pages) DAV-DZ660 (116 pages) HT-1750DP (48 pages) HT-SF1200 (68 pages) HT-CT350 (180 pages) HT-CT350 (180 pages) HT-DDW890 (80 pages) HT-DDW790 (64 pages) DX255 (100 pages) 4-178-247-11(1) (76 pages) NHS-130C (3 pages) DAV-SR4W (108 pages) HT-SF1300 (72 pages) HCD-HDX267W (104 pages) DAV-DZ171 (76 pages) DAV-DZ170 (2 pages) DAV-DZ170 (76 pages) Sitemap Remarks
Item Number Data
Item Upper byte Lower byte Data Upper byte Lower byte
Status Error 01h 01h No Error 00h 00h Get only
Lamp Error 00h 01h
Fan Error 00h 02h
Cover Error 00h 04h
Temp Error 00h 08h
D5V Error 00h 10h
Power Error 00h 20h
Temp Warning Error 00h 40h
NVM Data Error 00h 80h
Status Power 01h 02h Stanby 00h 00h
Start Up 00h 01h
Start Up Lamp 00h 02h
Power On 00h 03h
Cooling1 00h 04h
Cooling2 00h 05h
Saving Cooling1 00h 06h
Saving Cooling2 00h 07h
Saving Stanby 00h 08h
Control Mode 01h 05h User Mode 00h 00h
Service Mode 00h 01h
Lamp Timer 01h 13h Lamp Use Time 0000h-FFFFh *1
ROM Version 01h 1Dh MAIN ROM Version *2
SC ROM Version 01h 1Eh SC ROM Version *2
NVM Data VERSION 01h 27h NVM data VERSION *3
W/B All Save 03h 04h _ 00h 00h Set only
W/B Low Save 05h
W/B High Save 06h
W/B Middle Save 07h
W/B Custom1 Save 08h
W/B Custom2 Save 09h
W/B Custom3 Save 0Ah
Sircs(15 bit category) 17h Refer to Table4 _ 00h 00h Set only *4
Sircs(20 bit category) 19h Refer to Table5 _ 00h 00h
*1 Example) In case the lamp timer indicates 1000H, return values are [03h] upper byte and [E8h] lower byte.
*2 Example) In case the software version is 1.03, return values are [01h] upper byte and [03h] lower byte.
*3 Example) In case the NVM data version is 3, return values are [00] upper byte and [03] lower byte.
*4 It is corresponded to single command only.
