Sony SU-W210 User Manual
Page 9

9
2
Attach bracket D to bracket C, and secure them firmly
with two of the supplied screws.
Place bracket D onto bracket C as illustrated below, and secure them
with the two screws.
3
Attach bracket E to bracket C, and secure them firmly
with two of the supplied screws.
Slide the shaft of bracket E into the notches of bracket C as illustrated
below, and secure them with the two screws one on each side. When you
complete attaching bracket E, remove the soft mat from the rear cover
of the TV.
Note
Be careful not to get your fingers caught between the brackets when attaching them.
Bracket D
Bracket E
Shaft
continued
