Sony KV-36HS420 - Manual

KV-36HS420
MODEL:
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT: POWER
REQUIREMENTS:
POWER
CONSUMPTION: 36" Wega
®
Monitor/Receiver
120VAC
60Hz
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
FRONT VIEW
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX (201) 930 7891 • b2b.sel.sony.com/dn
SIDE VIEW
TOP VIEW JACK PACK
39 1/8"
14 1/2"
19 1/4"
IR RECEIVER
25"
22 7/8 "
24 "
39 1/8 "x 30 5/8 " x 25 "
230 lbs 240 w
1w(stby)
30 5/8"
4 7/8 "
NOTE: This drawing is based on prototype and/or pre-production models, not final
product and should be used to estimate space and electrical requirements only!
2 7/8"
29 1/4 "
22 1/4 "
Video
VIDEO IN
Audio
L (MONO)
R
MONITOR
OUT
S Video
AUDIO
OUT
Y
Pb
Pr
HDMI IN
COMPONENT / HD IN
R L
AUDIO
CONTROL S
OUT
VHF/UHF
IN
FIX/VAR
1 3 4
