Contractor's
Notes:
KV-32V26/36
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
POWER
REQUIREMENTS:
POWER
CONSUMPTION:
1/8 inch = 1 inch Scale 8:1
32" Trinitron ®
Monitor/Receiver
32 3/8" x 26 5/8" x 23 1/8"
120V AC
60Hz
185w(max)
5w(stby)
114 lbs 11 oz
Sony Electronics Inc • Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FA(201)X 930-7891
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
FRONT
VIEW
32 3/8"
26 5/8"
26 1/8"
19 3/4
SIDE
VIEW
26 5/8"
22 3/4"
23 5/8"
