Sony HT-CT260 - Manual (Page 41)

41 US
Ad
dit
iona
l Info
rmat
ion
Sound Bar (SA-CT260)
Amplifier section
U.S. models:
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION:
(FTC)
Front L + Front R:
With 3 ohms loads, both channels driven,
from 200 - 20,000 Hz; rated 25 Watts per
channel minimum RMS power, with no
more than 1 % total harmonic distortion
from 250 milliwatts to rated output.
POWER OUTPUT (reference)
Front L/Front R: 85 W
(per channel at 3 ohms, 1 kHz)
Canadian models:
POWER OUTPUT (rated)
Front L + Front R: 35 W + 35 W
(at 3 ohms, 1 kHz, 1 % THD)
POWER OUTPUT (reference)
Front L/Front R: 85 W (per channel at
3 ohms, 1 kHz)
Inputs
ANALOG
OPTICAL
COAXIAL
Bluetooth section
Communication system
Bluetooth Specification version 2.1 +
EDR (Enhanced Data Rate)
Output
Bluetooth Specification Power Class 2
Maximum communication range
Line of sight approx. 10 m
1)
Frequency band
2.4 GHz band (2.4000 GHz - 2.4835
GHz)
Modulation method
FHSS (Freq Hopping Spread Spectrum)
Compatible Bluetooth profiles
2)
A2DP (Advanced Audio Distribution
Profile)
AVRCP 1.3 (Audio Video Remote
Control Profile)
Supported Codecs
3)
SBC
4)
Transmission range (A2DP)
20 Hz - 20,000 Hz (Sampling frequency
44.1 kHz)
1) The actual range will vary depending on
factors such as obstacles between devices,
magnetic fields around a microwave oven,
static electricity, cordless phone, reception
sensitivity, operating system, software
application, etc.
2) Bluetooth standard profiles indicate the
purpose of Bluetooth communication
between devices.
3) Codec: Audio signal compression and
conversion format
4) Subband Codec
Front speaker unit
Speaker system
Full range speaker system, Bass Reflex
Speaker unit
55 mm × 80 mm (2 1/4 in × 3 1/4 in),
cone type
Rated impedance
3 ohms
Power requirements
120 V AC, 60 Hz
Power consumption
On: 32 W
Standby mode: 0.3 W or less
Bluetooth Standby mode: 3 W or less
Dimensions (approx.)
940 mm × 102 mm × 89 mm (37 1/8 in ×
4 1/8 in × 3 5/8 in) (with stands)
940 mm × 89 mm × 97 mm (37 1/8 in ×
3 5/8 in × 3 7/8 in) (without stands)
Mass (approx.)
2.8 kg (6 lb 2 3/4 oz)
Subwoofer (SA-WCT260)
POWER OUTPUT (reference)
130 W (per channel at 4 ohms, 100 Hz)
Speaker system
Subwoofer, Bass reflex
Speaker unit
130 mm (5 1/8 in) cone type
Rated impedance
4 ohms
Power requirements
120 V AC, 60 Hz
continued
