You can enjoy connected components via the system’s speakers.
Portable audio source (not supplied): G
DIGITAL MEDIA PORT adapter: H (TDM-iP20 is supplied. You can also use other DIGITAL
MEDIA PORT adapters.)
Tip
• You can connect another component, such as a VCR, digital satellite receiver, or PlayStation, to the TV/VIDEO
(AUDIO IN R/L) jacks or DIGITAL IN OPTICAL/COAXIAL jacks instead of the TV.
Connecting the other components
CENTER
SUBW OOFE R
HDM I OUT
SPEA KER
COAXIAL 75
AM
FM
ANTE NNA
DMP ORT
DC5V
0.7A M AX
AUDIO IN
P B /C B
P R /C R
Y
L
R
VIDEO
OUT
TV/VIDEO
COM PONE NT VI DEO OUT
DIGITAL IN
COAXIAL
OPTICAL
TV
FRONT R
FRONT L
SUR R
SUR L
SPEA KER
EZW- RT10
H DIGITAL MEDIA PORT
adapter (page 60)
To a portable audio source
G Stereo mini-plug cord
(not supplied)
Note
• Connect the DIGITAL MEDIA PORT
adapter so that the V marks are aligned.
When disconnecting, pull out while
pressing .
