9
FWD-50PX2
DNS Primary
Syntax Header Category Function Data1 Data2 Data3 Data4 Data5 Check Sum
Control 0x8C 0x00 0x63 0x05 Address 0 Address 1 Address 2 Address 3 0xXX
0x00-0xFF 0x00-0xFF 0x00-0xFF 0x00-0xFF
DNS Secondary
Syntax Header Category Function Data1 Data2 Data3 Data4 Data5 Check Sum
Control 0x8C 0x00 0x64 0x05 Address 0 Address 1 Address 2 Address 3 0xXX
0x00-0xFF 0x00-0xFF 0x00-0xFF 0x00-0xFF
Answer Header Answer Check Sum
Control 0x70 0x00 0x70 Completed
0x70 0x03 0x73 Command Canceled
IP Address ex)
192.128.14.1
→ 192 (0xC0) Address 0
128 (0x80) Address 1
14 (0x0E) Address 2
1 (0x01) Address 3
* IP Address command can be carried out even in the standby state.
Code Table(1-a)
[a]Function [b]Range/Switch code Command
Control
Enquiry Standby Power On
0x42 IP Address Yes Yes Enable Enable
0x61 Subnet Mask Yes Yes Enable Enable
0x62 Gateway Address Yes Yes Enable Enable
0x63 DNS Primary Yes Yes Enable Enable
0x64 DNS Secondary Yes Yes Enable Enable
(b) Color Matrix
Syntax Header Category Function Data1 Data2 Data3 Data3 Check Sum
Control 0x8C 0x00 Code Table(1-b)[a] 0x04 Code Table(1-c) Code Table(1-b)[b] Code Table(1-d) 0xXX
Syntax Header Category Function Data1 Data2 Check Sum
Enquiry 0x83 0x00 Code Table(1-b)[a] Code Table(1-c) Code Table(1-d) 0xXX
Answer Header Answer Check Sum
Control 0x70 0x00 0x70 Completed
0x70 0x03 0x73 Command Canceled
Answer Header Answer Return to Data Size Return Data1 Return Data2 Return Data3 Check Sum
Enquiry 0x70 0x00 0x04 Code Table(1-c) Code Table(1-b)[b] Code Table(1-d) 0xXX Completed
