D U E TO O N G O I N G P R O D U C T I M P R O V E M E N T , S P E C I F I C AT I O N S A R E S U B J E C T TO C H A N G E W I T H O U T N O T I C E . P R I N T E D I N U . S . A . #425 - 1/08
ITEM NO
. _______________________
COMBITHERM
®
6 10
ES
i
E L E C T R I C C O M B I N AT I O N OV E N / S T E A M E R
W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
PHONE : 262.251.3800 800.558.8744 U . S . A ./ CANADA FAX : 262.251.7067 800.329.8744 U . S . A . ONLY
www.alto-shaam.com
MODEL 6•10 ES i DELUXE
CAPACITY OF SIX (6) FULL - SIZE OR GN 1/1 PANS ,
SIX (6) HALF - SIZE SHEET PANS
SHOWN WITH OPTIONAL MOBILE STAND 5006188
ANSI/NSF 4
MODELS:
■ ■
6•10
ES
i:
STANDARD
■ ■
6•10
ES
i:
DELUXE
■ ■
6•10 ES i: S - CONTROL
STANDARD FEATURES AND ACCESSORIES
• Three (3) stainless steel shelves
• Two (2) stainless steel side racks with
Six (6) non-tilt pan support rails
21-1/16" (535mm) horizontal width between rails
2-5/8" (65mm) vertical spacing between rails
• Four (4) adjustable legs
• One (1) hand-held shower with backflow preventer
PATENT PENDING
• One (1) flush-mounted rotary door latch with steam venting position
• Single-point detachable temperature probe
( OPTIONAL ON S - CONTROL MODELS )
SHORT FORM SPECIFICATIONS:
Provide Alto-Shaam Combitherm® Model 6•10 ES i flash-steam combination oven/steamer designed with EcoSmart™ technology for
reduced energy and water usage and include operational modes for steam, convection, and a combination of steam and convection heat.
Standard features to include patented, automatic steam venting; Gold-n-Brown™ browning function; and a self-adjusting, flush-mounted
rotary door handle with a steam venting safety stop. Control to include 2-speed fan and cool-down function. Oven cavity is to be
constructed of 18 gauge stainless steel, include an attached spray hose with backflow preventer, and automatic cleaning function. The
oven is to accommodate up to 6 half-size sheet pans or 6 full-size hotel pans, include a removable door gasket for easy replacement, and
standard right-hand door hinging. The oven is to include the patented smoking function (only if requested with order) .
STANDARD CONTROL: To include removable quick-connect internal product temperature probe in the oven interior.
DELUXE CONTROL: To include removable quick-connect internal product temperature probe in the oven interior
and programming capability with Rapid-Touch™ operational quick-keys.
S-CONTROL: To include removable quick-connect internal product temperature probe in the oven interior
and smoking function as an option.
●
Flash-steam generation makes
conventional steam generator obsolete:
— Eliminates steam generating boiler maintenance
— Ends boiler heating element burn-out
— Maintains steam levels without a water reservoir
●
Cook by internal product temperature or time with temperature
variable steam, convection heat, or a combination of both to roast,
steam, bake, or oven-fry in a single piece of equipment.
●
Provides increased food quality and expands menu options
while increasing production efficiency and speed by as much
as 70-percent compared to conventional cooking methods.
●
EcoSmart
™
technology reduces energy cost by using less
electricity and water during both normal operation and the
cleaning function.
●
Gold-n-Brown™ feature provides the operator with the ability to
add additional product color.
●
AutoClean™ feature simplifies the cleaning process to a single
oven function.
●
Standard and Deluxe control offers 2-speed fan, a cool-down
feature, additional moisture injection, Delta-T cooking,
multiple language display, and other control features.
●
Enhanced safety feature includes automatic steam venting
immediately before cooking time expires.
PATENT #7,282,674
●
Optional patented smoking technology
(U.S. Pat. 7,157,668)
gives operators the unique ability to smoke any product,
hot or cold, and follow it with a non-smoked item without
any residual smoke flavor.
