SUGGESTED SPECIFICATION
TOP VIEW TOP VIEW
BT-80 & 100 FRONT VIEW BT-65 FRONT VIEW
DIMENSIONS IN INCHES (MILLIMETERS)
Model Approx. Ship.
No. A B C D E F G H J K L M Wt. (Lbs.)
--- 97.5 kg
724 1,286 25.4 12.7 303 123 kg
75.4 1,457 31.75 12.7 303 158.8 kg 705
27 3/4
24 65
1,378 610 1,651
26 1/2 61 1/8
673 1,553
68 5/8
1,743
Water heater(s) shall be Model ________________ as manufactured by A. O. Smith or an approved equal. Water heater(s) shall be of glass-lined design, and gas-fired,
equipped to burn __________ gas and design certified by the American Gas Association, (Canadian Gas Association) and shall be approved by the National
Sanitation Foundation (with optional leg kit). Heaters must meet all applicable energy codes. Heaters shall have an input rating of _____ BTU/H and a recovery
capacity of _____ GPH at a temperature rise of 100°F with a storage capacity of _____ gallons. Heater shall be equipped with a 2-3/4" x 3-3/4" boiler-type
handhole cleanout (except BT-65) and shall have a working pressure of 150 psi. Heater(s) shall be provided with an automatic gas shutoff device and safety shutoff
in event pilot flame is extinguished; a gas pressure regulator set for the type of gas supplied; an approved draft diverter, and extruded anode rod rigidly supported
for cathodic protection.
An A.G.A./ASME rated pressure and temperature relief valve shall be furnished and installed by manufacturer.
The tank shall be foam insulated. The outer jacket shall have a baked enamel finish over a bonderized undercoating. Fully illustrated instruction manual and
parts list to be included.
All internal surfaces of the heater(s) exposed to water shall be glass-lined with an alkaline borosilicate composition that has been fused-to-steel by firing at a
temperature range of 1400° to 1600°F. Heater tank shall have a three year limited warranty against corrosion and tank failure due to sediment build-up as outlined
in the written warranty. Heater(s) shall be design certified by A.G.A
Operation of the heater in a closed system where thermal expansion has not been compensated for with a properly sized expansion tank will void the warranty.
