53
O
the
r Inform
ation
For SU-WL500
Step 1: Check the parts required for the installation
Open the Wall-Mount Bracket package and check the contents for all required parts
along with the Instructions.
Step 2: Decide on the installation location
Decide where you want to install your TV. Refer to the TV installation dimensions table.
Refer to the Instructions for SU-WL500.
x Dimension Table
Figures in the above table may differ slightly depending on the installation.
CAUTION
The wall that the TV will be installed on should be capable of supporting a weight of at
least four times that of the TV. Refer to your TV’s operating instructions for its weight.
Step 3: Install the Base Bracket on the wall
Refer to the Instructions for SU-WL500.
Unit: mm
(inches) TV Dimensions Screen
center
dimensions
Length for each mounting angle Weight
Angle (0°) Angle (20°)
TV Model A B C D E F G H TV ×4
KDL-46BX451
KDL-46BX450 1,112
(43 7 /
8
)
675
(26 5 /
8
)
88
(3 1 /
2
)
426
(16 7 /
8
)
151
(6)
359
(14 1 /
4
)
640
(25 1 /
4
)
460
(18 1 /
8
)
16.0 kg
(35.3 lb.)
64.0 kg
(141.2 lb.)
KDL-40BX451
KDL-40BX450 980
(38 5 /
8
)
601
(23 3 /
4
)
122
(4 7 /
8
)
427
(16 7 /
8
)
151
(6)
334
(13 1 /
4
)
566
(22 3 /
8
)
460
(18 1 /
8
)
12.8 kg
(28.2 lb.)
51.2 kg
(112.8 lb.)
Screen center point
(Continued)
