67
O
the
r Inform
ation
Other Information
PC Input Signal Reference Chart for
HDMI/MHL IN
After connecting the PC to the TV, set the output signal from the PC according to the
chart below.
* The 1080p timing when applied to the HDMI/MHL input will be treated as a video timing and not
PC timing. This affects Picture settings and Wide Mode settings. To view PC content set Wide
Mode to Full, and Display Area to Full Pixel.
• This TV’s HDMI input does not support Sync on Green or Composite Sync.
• Your PC must support one of the above PC input signals to display on the television.
• In plug and play, signals with a 60 Hz vertical frequency will be detected automatically. (PC
reboot may be necessary.)
Resolution
Horizontal
frequency (kHz) Vertical
frequency (Hz) Standard
Signals Horizontal
(Pixel) × Vertical
(Line)
VGA 640 × 480 31.5 60 VGA
SVGA 800 × 600 37.9 60 VESA Guidelines
XGA 1,024 × 768 48.4 60 VESA Guidelines
WXGA 1,280 × 768 47.4 60 VESA
1,280 × 768 47.8 60 VESA
1,360 × 768 47.7 60 VESA
SXGA 1,280 × 1,024 64.0 60 VESA
HDTV* 1,920 × 1,080 67.5 60 CEA-861*
