17
Getting
Starte
d
2 Secure the TV to the stand.
Use the optional hardware listed below (not supplied):
• Machine screw (screwed into the screw hole of the TV).
• A screw or similar (attach it to the TV stand).
• Rope or chain (strong enough to support the weight of the TV). Make sure that there is
no excess slack in the rope or chain.
An alternative way to secure the TV is with an optional Sony Support Belt Kit.
The Sony Support Belt Kit is available as an optional accessory, depending on your
TV model.
The length of the machine screw differs depending on the rope or chain diameter.
Please refer to below illustration.
Screw hole of the TV
Machine screw
(not supplied)
Screw
(not supplied)
Rope or chain
(not supplied)
6-8 mm
Screw M4
rope or chain TV
10-16 mm
Screw M6
rope or chain TV
KDL-70R550A/70R520A KDL-60R550A/60R520A/50R550A
(Continued)
