18
FWD-40LX2F/40LX2X/32LX2F/32LX2X
KLH-W32/W26
(g) Auto Input Detect
Syntax Header Category Function Data1 Data2 Check Sum
Enquiry 0x83 0x30 0x30 0xFF 0xFF 0xE1
Answer Header Answer Return to Return Data1 Return Data2 Return Data3 Return Data4 Return Data5
Data Size
Enquiry 0x70 0x00 0x0C Input1 Input2 Input3 Input4 Input5
Input Type Input Type Input Type Input Type Input Type
Code Code Code Code Code
Table (4-e) Table (4-e) Table (4-e) Table (4-e) Table (4-e)
Return Data6 Return Data7 Return Data8 Return Data9 Return Data10 Return Data11 Check Sum
Option1 Option1 Option2 Option2 Option3 Option3 0xXX Completed
Option Type Input Type Option Type Input Type Option Type Input Type
Code Code Code Code Code Code
Table (4-e) Table (4-e) Table (4-e) Table (4-e) Table (4-e) Table (4-e)
FWD-40LX2F/40LX2X/32LX2F/32LX2X
Input Input Type (Basic) Option Type Input Type (Option)
INPUT1 0x06 RGB/YUV (Analog)
INPUT2 0x08 HDMI
INPUT3 0x08 HDMI
INPUT4 0x00 No Input
INPUT5 0x00 No Input
OPTION1 0x00 Analog Only 0x00 No Input
0x00 Analog Only 0x03 Video/S-Video
0x00 Analog Only 0x06 RGB/YUV (Analog)
0x00 Analog Only 0x07 Video/S-Video/RGB/YUV (Analog)
0x03 Com Only 0x00 No Input
OPTION2 0x00 Analog Only 0x00 No Input
0x00 Analog Only 0x03 Video/S-Video
0x00 Analog Only 0x06 RGB/YUV (Analog)
0x00 Analog Only 0x07 Video/S-Video/RGB/YUV (Analog)
0x03 Com Only 0x00 No Input
OPTION3 0x00 Analog Only 0x00 No Input
