As illustrated on the right, attached
to the unit bottom are the lock
screws that stabilize the unit for
transportation (two lock screws and
one lock stick).
Since the unit is inoperable with
them attached, be sure to remove
them before installing. Then close
the holes with the supplied dust-
tight seals (included in the
accessory box).
See “Unpacking Guide” or
“Operating Instructions” for details.
Important Notice Remove the Two Lock Screws and Lock Stick
Unit bottom
Unlock the lock stick clockwise
90 degrees and remove it.
 Lock Screws (2)
 Lock Stick (1)
Lock screws and lock stick
Please store the screws and stick in a safe place.
Lock Screws and Lock Stick are necessary to prevent
damage to the disc pickup mechanism during
shipping and transport.
Lock Screws and
Lock Stick
Dust-tight
seals
