Sony KE-42TS2 - Manual

MODEL:
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
KE-42TS2
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT: POWER
REQUIREMENTS:
POWER
CONSUMPTION: 42" Flat Panel
TV
41 5/8 " X 30 1/8 " X 5 "
81 lbs 9 oz.
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX (201)930 7891 • b2b.sel.sony.com
415W
2.9w Stby
120V AC
60Hz
RM-923Y REMOTE CONTROL
SIDE VIEW
17 1/8"
30 1/8"
13 1/8"
VIDEO L AUDIO R VIDEO 1 VIDEO S-VIDEO
VIDEO 2
AUDIO R L COMPONENT VIDEO 1
COMPONENT VIDEO 2 / RGB
Y Pb Pr
Y/G Pb/B Pr/R
AUDIO R L AUDIO OUT
HD VD CONTROL S
SUB OUT IN
OUT
VENTILLATION
VENTILLATION
EXHAUST
VENTILLATION
8 1/2"
12 1/4"
11 1/4"
BACK VIEW
TOP VIEW
FRONT VIEW
41 5/8"
30 1/8"
27 3/4"
5 "
22 1/4"
Stand is
removeable
37"
21 1/4"
6 5/8"
REMOTE
SENSOR
SPEAKERS SPEAKERS
1/8"
CONTROLS
JACK PACK
DVI/HDTV IN
AUDIO R L JACK
PACK
VIDEO L AUDIO R
VIDEO 1 IN
VIDEO S-VIDEO
VIDEO 2 IN
AUDIO R L
VIDEO IN 3
Y/G Pb/B Pr/R
AUDIO R L
AUDIO OUT
HD VD CONTROL S
SUB
OUT
IN
OUT
VHF/UHF
AC IN
AUDIO R L DVI/HDTV
VIDEO IN 4
