SPECIFICATIONS
- 5 -
PICTURE TUBE(Useful screen size)
POWER SOURCE
POWER CONSUMPTION
SYSTEM
RESOLUTION
INPUT SIGNAL
SCANNING FREQUENCY
:
:
LINEARITY
:
:
ACTIVE DISPLAY AREA
:
:
INPUT CONNECTOR(CAMERA)
CONTROL
:
:
OPERATING TEMPERATURE
AMBIENT HUMIDITY
DIMENSIONS(W x D x H)
WEIGHT
HORIZONTAL
VERTICAL
HORIZONTAL
VERTICAL
HORIZONTAL
VERTICAL
FRONT
BACK
CAUTION : Confirm the model number and the power source on the cover
page before use.
9" Diagonal, 90° Deflection Angle ( 8.7")
12" Diagonal, 90° Deflection Angle (11.6")
AC 90 132V 50Hz/60Hz
AC 198 264V 50Hz/60Hz
18 Watts
EIA or CCIR standard
more than 800 TV lines (center)
1.0Vp-p (75 ohm)
60Hz : 15.734KHz
50Hz : 15.625KHz
59.94Hz
50Hz
10% MAX.
10% MAX.
10% overscanning
13% overscanning
BNC connector
H-HOLD, V-HOLD, BRIGHT, CONTRAST,
POWER S/W
V-LINEARITY , V-HEIGHT,
EIA/CCIR SELECTOR S/W
0°C ~ 40C° (32°F ~ 104°F)
0% ~ 90%
9" : 220mm x 248mm x 234mm
12" : 305mm x 302mm x 287mm
9" : 4.3Kg
12" : 7.3Kg
