4-2
DuraLAN Fast Ethernet NICs User’s Guide
Network Without Duralink64 Failover
Protection
This configuration uses one NIC connected to a hub or switch on an
Ethernet segment. If the NIC fails, all network traffic is stopped.
Figure 4-1. Network without Duralink64 Failover protection
Server
Ethernet Switch or
Ethernet Hub
Clients
