A-3
Cables and LEDs
Cable Requirements
Cable requirements for Adaptec DuraLAN NICs vary according to
network speed, cabling standard, and the connector to be used. The
table below identifies appropriate cabling, based on these variables.
The table applies to both Half Duplex and Full Duplex (for selected
models) environments.
NIC
Connector
10 Mbps
100 Mbps
Cable
Pins Used
TX Adapters
RJ-45
CAT 3,4,5
UTP
CAT 5 UTP,
1,2,3, 6
FX Adapters
ST
N/A
62.5/125
micron
multimode
fiber
N/A
SC
N/A
62.5/125
micron
multimode
fiber
N/A
