11-12
DuraLAN Fast Ethernet NICs User’s Guide
Assigning Protocols
You can assign the IP or IPX protocols to groups and stand-alone
ports. The IPX protocol supports the following frame types
simultaneously:
■
ETHERNET_802.2
■
ETHERNET_802.3
■
ETHERNET_II
■
ETHERNET_SNAP
IP supports either
ETHERNET_II
or
ETHERNET_SNAP
, but never both
at the same time.
1
In the Main Menu, select Configure Protocols, and then press
Enter
.
2
In the List of Ports/Groups box, select the group or port, and
then press Enter. The virtual port— Marcom—requires one
protocol only.
1
Figure 11-21. List of Ports/Groups Box
1
Refer to the List of Existing Groups box to verify which ports are assigned to a
particular group.
List of Ports / Groups
1 P Adptsf4
2 P Adptsf5
3 P Adptsf6
4 P Adptsf7
5 P Adptsf 8
6 G Marcom (FEC)
G=Group
P=Port
